ZAVOLI 100 PAN 1CYL Autogas Injector
- SKU:
- 120800
- Weight:
- 0.15 KGS
- Shipping:
- Calculated at Checkout
Description
ZAVOLI PAN Single LPG CNG Injector
Italian brand ZAVOLI is known for its uncompromising quality but everything sometimes brakes that is why we introduce this spare 100 PAN autogas injector.
The PAN injector has been designed to turn the gas flow coming from the Regulator on and off. When the Injector is turned on, the gas flow is conveyed to the engine through a pipe fixed to the intake manifold on the engine head side. One of the characteristics making the PAN injector installation so versatile is its modularity: according to the type of engine, it can be assembled individually, in pairs of injectors etc. The electric input to the injectors is supplied by individual plugs connected to the main electric harness. The connectors are gas tight and have a protection rating of IP 54. All components are type-approved as per European standards 10R-02 (Electromagnetic compatibility) 67R-01, 110R-00.
TECHNICAL DATA SHEET | |
ITEM | DETAIL |
Working Pressure | 0.5 to 2.0 bar |
Max Pressure | 4,5 bar |
Coil Resistence | 3 ohm |
Alimentation | 12v ± 15% |
Peak current time | 4 A |
Minimun Injection Pulse | 3.6 ms |
Inlet gas fitting | Rubber hose Ø 10 mm |
Outlet gas fitting | Calibrated nozzles M 4x0,5 / external Ø 6,2 mm |
Calibrated hole range (for nozzles) | 1.7 to 3.0 mm |
T range | -40/ +120° C |
Agreement | 67R-01 / 110R-00 |
