Tomasetto Reducer
Tomasetto AT04 140HP CNG Natural Gas Reducer
- SKU:
- 230104
- UPC:
- 59.89
- Weight:
- 2.00 KGS
- Shipping:
- Calculated at Checkout
Description
Tomasetto AT04 RMAT1010 CNG (Methane) Gas Pressure Regulator for up to 140 HP
Producer Code: RMAT1010
The CNG reducer model AT04 is an electronic CNG pressure reducer with 3 pressure reduction stages, for traditional systems. AT04 reducer is homologated in accordance withECE 110 and in conformity of ISO 15500 Regulation. Compact and very reliable, this reducer has a double regulation system, that allows always the best performance. There are 3 different versions, suitable for different power engines:
Technical data
Dimension: 154,5x190x110 mm
Material: Die-cast Aluminium body, CNC machined
Weight: 2 kg
Type of product: CNG traditional reducer
Max. inlet pressure: 26,00 MPa
Coil voltage: 12V DC
Coil power: 15W
Inlet connection: Ø 6.0 mm M12x1
Outlet connection: Swivel plastic pipe Ø 19mm
Flow rate: 30 kg/h CH4
