OMVL (REG) Dream XXI N – M 230HP CNG Reducer

(No reviews yet) Write a Review
SKU:
230105
UPC:
89.99
Weight:
2.00 KGS
Shipping:
Calculated at Checkout
  • OMVL (REG) Dream XXI N – M 230HP CNG Pressure Reducer Regulator Vapourizer Natural Gas
  • OMVL (REG) Dream XXI N – M 230HP CNG Pressure Reducer Regulator Vapourizer Natural Gas
£94.49 Inc. VAT
£78.74
Ex. VAT

Description

OMVL (REG) Dream XXI N – M CNG (Methane) Gas Pressure Regulator for up to 230HP

DREAM XXI N – M (CNG)
The system reduces CNG gas pressure from 200–220 bar to 1.8bar. The pressure reduction unit is a water-gas heated two stage, servo-assisted membrane unit.

DREAM XXI N is an advanced gaseous fuel injection system, designed for use with current petrol (gasoline) fuelled vehicles. The natural gas or LPG is delivered from the tank to the Pressure Regulator, which supplies it at a constant pressure to the Injection Unit. This is controlled by the Electronic Control Unit that calculates the correct gas injection time into the intake manifold based on the vehicle's original petrol injection time and other system parameters.

The pressure stability of the regulator, together with sophisticated electronic fuel delivery control, creates robust power performance, and a smooth acceleration from “cut-off” phase. DREAM XXI N also optimises consumption and performance.



DREAM N Reducer technical data:

  • Gas inlet: femal connector with bicone for 6mm diameter pipe
  • Gas outlet: male connector for rubber hose, internal 12mm, external 19mm
  • Coolant inlet/outlet: male connector for rubber hose, internal 14mm, external 22mm
  • Solenoid power: 12V DC
  • Gas pressure reduction stages: two
  • Gas delivery pressure: 1.8bar
  • CNG shut-off solenoid: included
  • Compensation socket: YES
  • Coolant thermostat: YES
  • Gas temperature sensor: YES
  • Operating temperature: -40 to 120 Celsius
  • Installation: inside engine compartment, vertical position of solenoid valve
  • Homologations: E4-110R-00






Warranty Information

24 months producer warranty.
