HANA H2001 GOLD 3CYL SET Hose Type with Distributor

(No reviews yet) Write a Review

SKU:: 120204
UPC:: 51.09
Weight:: 0.90 KGS
Shipping:: Calculated at Checkout

£53.69 Inc. VAT

£44.74

Ex. VAT

Current Stock:

Quantity:

Description
Warranty Information
0 Reviews

Description

HANA H2001 GOLD 3 Cylinder Single Mount with Distribution Rail (included), Valtek connector, LPG/CNG Injector

HANA LPG/CNG Injectors with long lifespan (around 500 milion cycles) are one of the best on the market. HANAs are very competitive to and easy swappable with japanese Keihin injectors.

New HANA injectors – GOLD are designed for easier assembly on any vehicle. The previous colours, GREEN, RED, BLACK and VIOLET (marked on every injector) have been discontinued and replaced by HANA GOLD.

HANA GOLD injectors provides a full range of flow, GREEN, RED, BLACK and VIOLET and are adjusted by output bras nozzles (HANA OEM supplied)

Nozzles sizes are marked by stripes so there is no place for mistakes.

HANA A+ BLUE range has not changed!

Choose a proper nozle size or leave us an info regarding HP and number of cylinders.

HANA GOLD Injectors (depend on the nozzle size) works with following Horse Power:

3 Cylinders: 45~150HP
4 Cylinders: 60~200HP
6 Cylinders: 90~300HP
8 Cylinders: 120~400HP

HANA Injectors comparision chart:

NEW HANA	Former HANA	Nozzle		Maximum Power (HP)				Mesured with
NEW HANA	Former HANA	Nozzle		HP/Cylinder (±15%)	4 Clinders	6 Cylinders	8 Cylinders	Mesured with
Type A+ (BLUE)	Type A+ (BLUE)		1.3 Ohm	40 / 50 / 60 HP	160 ~ 240 HP	240 ~ 360 HP	320 ~ 480 HP	Pressure 0.8/1.0/1.2 bar (with max.load)
Type A (GOLD)	Type A (GREEN)		1.9 Ohm	33 / 42 / 50 HP	132 ~ 200 HP	198 ~ 300 HP	264 ~ 400 HP
	Type B (RED)	2.4mm One stripe \|	1.9 Ohm	26 / 32 / 39 HP	104 ~ 156 HP	156 ~ 234 HP	208 ~ 312 HP
	Type C (BLACK)	2.1mm Two stripes \|\|	1.9 Ohm	20 / 25 / 30 HP	80 ~ 120 HP	120 ~ 180 HP	160 ~ 240 HP
	Type D (VIOLET)	1.9mm Three stripes \|\|\|	1.9 Ohm	15 / 19 / 24 HP	60 ~ 96 HP	90 ~ 144 HP	120 ~ 192 HP
