EMER (OMVL) Palladio 350HP High Power Reducer

(No reviews yet) Write a Review
SKU:
131306
Weight:
2.30 KGS
Shipping:
Calculated at Checkout
  • emer omvl palladio 350 hp 8mm autogas pressure reducer regulator vapourizer high power
  • emer omvl palladio 350 hp 8mm autogas pressure reducer regulator vapourizer high power
143.86$
Inc. VAT
119.88$
Ex. VAT

Description

EMER OMVL Palladio 350 HP reducer with integrated 8mm valve for large engines



One of the most populars and robust autogas reducer with integrated solenoid valve and temperature sensor dedicated for large sequentially injected petrol engines. Gas inlet 8mm, water - coolant connections 16mm, gas outlet 12mm. Formerly called EMER later taken over by OMVL Westport group.





Characteristic:

  • Single stage membrane type reducer
  • Stable pressure output in variable loads
  • Adjustable output gas pressure from 1 to 1.5 bar
  • Aluminium body for vapourizing high flow of LPG
  • Hydraulic capacity of reducer: 150cc
  • Integrated security valve adjusted for 6 bar
  • Integrated temperature sensor 4.7kΩ
  • ECE R67-01 approvals



TECHNICAL SPECIFICATIONS

Material Aluminum
Type Membrane single reduction stage
Operating temperature -20 °C » +120 °C
Max. inlet pressure 27 bar
Output setting pressure
(adjustable)
0,9 » 1,1 bar
1,2 » 1,6 bar
Gas outlet hose connection ø 10 mm (straight fitting)
optional: 120° fitting
Coolant inlet / outlet hose connection ø 15 mm (120° fitting)
optional: straight fitting
Electrical connection AMP/DELPHI Superseal 1,5 mm IP67
Weight ca 2 Kg (with Solenoid Valve)
Approvals ECE R67





View AllClose

Warranty Information

24 months warranty. Easy swap.
