ALEX Shark 1200 Reducer 150HP with integrated filter and no valve
SHARK reducer is designed for sequential gas injection systems.
The unique and modern design ensures proper operating even in temperate climate conditions, which provides smooth operation of LPG in the user’s car.
The reducer is equipped with a gas filter for the liquid phase and the solenoid at high flow rates. As first company in Poland we have used the valve with a diameter of 8 mm, which means that there are no restrictions in the gas flow, which are strongly felt by huge expenditure in the standard solution of 3 mm diameter.
The special construction of the membrane ensures full performance and the lack of pressure drops across the full load range. While designing our product, we remembered about the possibility of mounting it in two surfaces, which in many cases makes an installation much easier for the installer. All that allows our SHARK reducer – based on proven, but also innovative solutions – to maintain long and trouble-free operation of the whole gas installation.
SHARK brand is a guarantee of quality and efficiency of the device.
- Integrated liquid phase filter
- Output pressure 1.2 bar
- Pressure adjustment range 1,0÷1,5 bar
- Engine power 150 KM
- Pressure regulation SW4
- Gas inlet port diameter Ø 6 mm
- Gas outlet port diameter Ø 12 mm
- Rotary water pipe elbows diameter Ø 16 mm
- Vacuum input Ø 5 mm
- Dimensions 95 x 109 x 93 mm
- Weight 1.6 kg
