Description

The base price is for bottle only with fully fitted valves. It does not come with any filler or other accessories unless options selected.

GAS IT Small 6kg Refillable LPG Gas Bottle

Safe refill GAS IT propane butane bottle with separate 3/4 UNF JIC type inlet and W21.8mm x 1/14 lh (G.8 standard) Shell type Left Hand thread outlet for gas regulators which can be used for BBQ, camping, cooking, heating at home, on campervan, caravan, motorhome, boat or for industrial burners and blowtorches.

This cylinder is equipped with automatic Overfill Protection Valve - it will cut off the gas supply from the pump once the bottle is filled up to 80% level.

PLEASE NOTE: Bottle must be vertically positioned to ensure proper work of overfill valve.

Moreover this bottle is equipped with special separate outlet valve with level sender and gauge which measures the level of the propane butane or LPG gas in the bottle.

One of the great advantages of the separate inlet is that it allows you to use an external filling point (with different standards ie. UK or European one) so that the bottle can be refilled at Autogas stations in a discrete manner, without removing the bottle from the lock each time. A separate outlet on the other hand, allows you to keep the gas regulator permanently attached to the bottle, without the need of removing it for refilling.

Specification

  Small 6kg Large 11kg
80% gas capacity 12 litres 22 litres
Empty weight 12kg 15kg

Full weight

14.7kg 21.9kg
Height with handle 49.5cm 58.5cm
Height without handle 47cm 53cm
Diameter 25cm 30.5cm
Inlet thread 3/8"NPT without elbow
JIC 3/4" with elbow
Outlet thread Shell G.8 Standard
W21.8 left thread



Options explained

Filling point - Direct refill UK nozzle on the top
The bottle can be refilled by attaching the UK bayonet filling nozzle from the top, directly to the inlet valve.


Filling point - Direct refill UK nozzle on the side
The bottle can be refilled by attaching the UK bayonet filling nozzle from the side, directly to the inlet valve. The handle has to be removed in order to connect filling nozzle.


Filling point - Remote filling point underneath vehicle
The filling point bolted to the chassis. The easiest option for external filling point.



Filling point - Remote filling point in recessed white box
Recessed filling point in white box. Requires 70mm hole to be drilled in the body. Total length is about 9cm.



Filling point - Remote filling point in recessed box black
Recessed filling point in black box. Requires 70mm hole to be drilled in the body. Total length is about 9cm.

Filling point - Remote filling point flat
Recessed flat filling point with detachable adapter. Requires 28mm hole to be drilled in the body. Total length is about 9cm.
Filling hose - Polypipe Cut-to-length 3 meter
67R approved polypipe, very flexible, easy to work with. Can be cut to length using sharp knife. Comes with P clips and fittings
Filling hose - JIC
Thick rubber hose, made to length.
Level indicator - Mechanical level indicator
Simple arrow level indicator to attach to the outlet neck.
Level indicator - Bluetooth Tank Check
Digital Bluetooth indicator with magnet holder to stick to the bottom of the cylinder. Level can be checked at Android or iPhone app.
Pressure regulator - Simple Gas Regulator 30mbar
Basic single stage regulator with attachment for 8mm orange hose. Fit directly onto the bottle. Not suitable for moving vehicles.

Pressure regulator - Two Stage 30mBar for Motorhomes Angled
Campervan approved two stage regulator with test point - better pressure stability. Comes with pigtail.

Pressure regulator - Two Stage 30mBar for Motorhomes
Campervan approved two stage regulator with test point - better pressure stability. Comes with pigtail.

Pressure regulator - Changeover Switch Gas Regulator 30mBar
Approved two stage regulator with changeover switch. Empties one bottle at the time.

European adapters - Set of 3 European adapters
Must have for overseas journeys. This set covers all Europe.
