5/6/8CYL ECU: KING AEB OBDII

(1 review) Write a Review
SKU:
110153
UPC:
172.29
Weight:
2.58 KGS
Shipping:
Calculated at Checkout
  • KING 5 6 8 Cylinders LPG Autogas Conversion ECU with Harness
  • KING 5 6 8 Cylinders LPG Autogas Conversion ECU with Harness
  • KING 5 6 8 Cylinders LPG Autogas Conversion ECU with Harness
£172.29 Inc. VAT
£143.57
Ex. VAT

Description

KING 5/6/8 CYLINDERS OBDII ECU

The new King 5-6-8CYL OBDII ECU, manufactured by AEB, has been designed to enable conversions of 5-, 6- and 8-cylinder engines equipped with sequential petrol injection. The controller offers high efficiency, but is at the same time compact in size and easy to fit.



Box include:

  • ECU control unit
  • MAP sensor (pressure and vacuum)
  • Switch with push button
  • Wiring harness
  • Accessories
  • Instructions



Technical specification:

  • Supply voltage: Vbatt=10÷16V
  • Operating temperature: -40÷120°C
  • Current absorption with the actuators disabled: Imax=0.5A
  • Actuators managed:
  • 8 gas injectors with the following characteristics Imax=6, Vbatt,max=16V
  • 2 power outputs for gas solenoid valves [Pmax=25W, Imax=2A (power and maximum current for each output with two outputs enabled)- Pmax=50W, Imax=4A (power and maximum current with just one output enabled)]
  • Sensors managed:
  • Gas pressure sensor: AEB025, 463500000, 463059000, 463505000
  • - MAP sensor: AEB025, 463500000, 463059000, 463505000, the car’s original sensor
  • - Level sensor: AEB level sensor, standard sensor 0-90Ohm, non standard sensor
  • Reduction gear temperature sensor: AEB sensor, type 369
  • Gas temperature sensor: AEB type sensor (4.7kOhm)
  • Oxygen sensor reading in voltage: 0-1V, 0-5V, 5-0V, 0.8-1.6V, 2.5-3.5V
  • Management of AEB119B type switch



Homologations:
  • 2006/28/CE
  • 10R-03
  • 67R-01
  • 110R-01
Installation manual:

Warranty Information

24 months producers warranty. Easy swap.
View AllClose

1 Review

  • 4
    Quality - Cost Competitive - WORKS !

    Posted by Rick on 27th Mar 2017

    Quick delivery time (to Australia)48Hrs.
    Arrived with all promised components and instructions.
    Easy fit, upload software and tune.
    Very Cost Competitive and WORKS!
